Lc Fiber Cable Meaning

Lc has a smaller connector housing and a smaller 1 25mm ferrule.

Lc fiber cable meaning. Fiber optics color standards. Lc is a fiber optic connector also called lucent connector little connector or local connector. You can fit more interfaces on line cards panels etc with lc connector. A connector by itself is simplex while a pair of connectors together is duplex.

Optical fiber connectors are used in telephone exchanges for customer premises wiring and in outside plant applications to connect equipment and fiber optic cables or to cross connect cables. A large variety of fiber connector types are available including lc fiber connector sc fiber connector fc fiber connector st fiber connector and so on. What s the meaning of upc and apc. When a signal is sent through a fiber cable it is one way.

Lucent connector a miniaturized version of the fiber optic sc connector. Fiber optic connector is a flexible device that can connect and disconnect fiber optic cable quickly. The coupling type of lc fiber optic connector is snap and its ferrule diameter is 1 25 mm. Sc used to be all the rage but now it s lc.

Sc has a larger connector housing and a larger 2 5mm ferrule. As we know fiber optic cable assemblies are mainly with connectors and cables so the fiber cable assembly name is related to the connector name. Os1 cables have a 0 25 db km attenuation at 1550 nm and 0 35 db km at 1310 nm. We call a cable lc fiber patch cable because this cable is with lc fiber optic connector.

This sm fiber has an yellow color jacket with a 3 00mm diameter. Giving each one a specific color allows better and faster recognition of the cable in use and avoids issues due to bad connections or confusions. All types of fiber cables come in either simplex or duplex configuration. Fs com lc fiber patch cables solution lc fiber connector adapter and cable.

It was invented by bell which makes a significant breakthrough for high density telecommunication. It looks somewhat like the sc but is half the size with a 1 25mm ferrule instead of 2 5mm. The standards for multimode cables are as follows. Among them lc fiber optic connector is one of the most common types of fiber optic connectors.

Duplex is the more common of the two since fiber cables are typically used in pairs. For its rj style latch clip design it is very easy to.
